*NEW* SBL Platinum PG-100C Folder Gluer

MATCH PRODUCT I.D.:

I.D.#PG100C

EQUIPMENT OVERVIEW

MANUFACTURER:

SBL

PRODUCT CATEGORY:

EQUIPMENT NAME:

*NEW* SBL Platinum PG-100C Folder Gluer

DESCRIPTION:

*NEW* SBL Platinum PG-100C Folder Gluer
Straight-Line Folding with Additional Side-Folding Belt in Pre-Break Section,
Crash-Lock Auto-Bottom with Pre-Break, 4 & 6 Corner Carton Folding,
Carton Alignment Section, (3) Moveable Carriers throughout Machine,
Programmable Pressurized Spray Glue System (8 channel, 6 guns, 4 photo eyes),
Small Box Attachment
Record Sleeve/Pocket Folder Attachment,
CD envelope; 1, 2, or 3 Pockets; with Rear Glue Tab
Reference #PG100C

DATE OF MANUFACTURE:

NEW OR PREVIOUSLY OWNED:

New Equipment

UNDER POWER:

CURRENTLY IN OPERATION:

GENERAL SPECIFICATIONS:

1000mm (39.36”) – Blank Width

Feed Material : Cardboard, corrugated and decorated board
Fundamental Pattern : Standard Folding Cartons, Double-Sided Cartons,
Crash-Lock Auto-Bottom Cartons, 4 & 6 Corner Cartons
Capacity : Maximum 300 m/min (990ft / min.)
Max. Blank Width : 1000mm (39.36”)
Pre-Folding : No. 1 creasing line 180º, No. 3 creasing line 135º
Feeding : Automatic and continuous feeding
Glue : PVA white glue
Power Requirements : 12 Kw, 220V, 60Hz
Air Requirement : 6 Bar (Max) 10M³/h
Net Weight : 6,800 kg. (14,960 lbs.)
